Description

Description Specifications gross capacity (litres) 185 total net capacity (litres) 170 net vaccine storage capacity 55 net freezer capacity (litres) 47 Input/Consumption gas inlet pressure propane (mbar) 30 standard voltage, 50/60 hz (vac)(vdc) 230 optional vac 120 and 240 optional vdc - max input (watt) 325 gas consumption/24 hrs (grams) 500 electric consumption/24 hrs (kw) 6.3 Features 100% galvanized steel yes lockable vaccine compartment yes electric thermostat yes gas thermostat yes defrosting, electric operation no automatic burner type SIBIR LPG piezo ignition yes flame indicator yes fuel supply interlock yes reversible door hang no shelves galvanized and lacquered wire level indicator yes Dimensions height over all (mm) 1456 width over all (mm) 592 depth over all (mm) 623 net weight (kg) 68 epi specification E3/RF.2 Performance according to EPI E3/PROC/5 stable running 32 ambient (ºc) min 2.8 max 5.8 stable running 43 ambient (ºc) min 1.5 max 5.8 safe ice pack freezing 32 ambient (ºc) 3.6 kg hold over time 32 ambient (ºc) 3.02 hrs day/night cycling 32/15 ambient min 0.2 max 5.1 Additional tests maximized safe ice pack freezing (3 batches) low ambient test, stable running at 15c ambient. all measurements were made at thermostat setting 3 7.2 kg Corrosion Standard (internal and external cabinet, lid and frame) DIN 8985 Shipping shipping weight (kg) 86 packing height (mm) 1525 packing width (mm) 695
